Networking Keystone Jacks
PC Cable World's variety of keystone jacks offer you the flexibility to manage your networking communications easily and efficiently.
CAT3 Keystone Jack
CAT3 SLIM KEYSTONE JACK (TOOL-LESS)
-
Category 3 RJ12 UTP Slim Keystone (6P6C) 16.6 x 31.5 x 22.3 mm
-
Use for voice and communications applications
-
Compatible with RJ11 or RJ12 modular phone cables
-
Terminate using110 punch-down tool
-
Snap in for use with standard sized wall plates, surface-mount boxes, or unloaded patch panels
-
90 ̊ wire connection
-
6 micro-inch gold plated contacts for superior transmission, high reliability and durability
-
PCB technology provides maximum performance and superior signal quality
-
Labelled with color-coded wiring diagram
-
Fireproof ABS UL-94V0 body
-
3P Third Party Tested, meets or exceeds C3 EIA/TIA standards, ETL Intertek listed
![](https://static.wixstatic.com/media/03a5b8_621ba34775b4413fbfbc96ebb363a512~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_621ba34775b4413fbfbc96ebb363a512~mv2.jpg)
Available Colour
CAT3 SLIM KEYSTONE JACK (110 PUNCH DOWN)
-
Category 3 RJ12 UTP Slim Keystone (6P6C) 16.6 x 31.5 x 22.3 mm
-
Use for voice and communications applications
-
Compatible with RJ11 or RJ12 modular phone cables
-
No tool required, can terminate with IDC cap or 110 punch-down tool
-
Snap in for use with standard sized wall plates, surface-mount boxes, or unloaded patch panels
-
90 ̊ wire connection
-
6 micro-inch gold plated contacts for superior transmission, high reliability and durability
-
PCB technology provides maximum performance and superior signal quality
-
Labelled with color-coded wiring diagram
-
Fireproof ABS UL-94V0 body
-
3P Third Party Tested, meets or exceeds C3 EIA/TIA standards, ETL Intertek listed
![](https://static.wixstatic.com/media/03a5b8_2a7e2decc52c453c9172a1c0ac267330~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_2a7e2decc52c453c9172a1c0ac267330~mv2.jpg)
Available Colour
![](https://static.wixstatic.com/media/03a5b8_621ba34775b4413fbfbc96ebb363a512~mv2.jpg/v1/fill/w_256,h_255,q_90/03a5b8_621ba34775b4413fbfbc96ebb363a512~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_2aa1519db8e9414ca12a8049a6485c78~mv2.jpg/v1/fill/w_255,h_255,q_90/03a5b8_2aa1519db8e9414ca12a8049a6485c78~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_014b8dcc80104b71849dc1fea6d12c06~mv2.jpg/v1/fill/w_521,h_521,q_90/03a5b8_014b8dcc80104b71849dc1fea6d12c06~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_d0219d75998a42c2b5e1d7530ee9fd17~mv2.jpg/v1/fill/w_388,h_388,q_90/03a5b8_d0219d75998a42c2b5e1d7530ee9fd17~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_78239201ba434b18bec8c8bbaf6e9d6b~mv2.jpg/v1/fill/w_388,h_388,q_90/03a5b8_78239201ba434b18bec8c8bbaf6e9d6b~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_a9e4a5ec487f4f28a7bc81e55dc26086~mv2.jpg/v1/fill/w_521,h_521,q_90/03a5b8_a9e4a5ec487f4f28a7bc81e55dc26086~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_2a7e2decc52c453c9172a1c0ac267330~mv2.jpg/v1/fill/w_256,h_255,q_90/03a5b8_2a7e2decc52c453c9172a1c0ac267330~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_b5f4633af2094cf2ac3c94716a2ae7c9~mv2.jpg/v1/fill/w_255,h_255,q_90/03a5b8_b5f4633af2094cf2ac3c94716a2ae7c9~mv2.jpg)
Networking Keystone Comparison Chart
CAT6A
C6A-71S
180 degree punch down
✓
RJ45
22-26 AWG
CAT6A Coupler
C6A-661
✓
✓
2 x RJ45
-
Category
Part #
Tool-Less
Shielded
Connector
Compatible AWG
Download (PDF)
![](https://static.wixstatic.com/media/03a5b8_439d76c282704eb097282fe82d81329c~mv2.jpg/v1/fill/w_214,h_215,q_90/03a5b8_439d76c282704eb097282fe82d81329c~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_e1a7161a423847f4ad25bcab16165ac2~mv2.jpg/v1/fill/w_215,h_215,q_90/03a5b8_e1a7161a423847f4ad25bcab16165ac2~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_5d7459b5673445fbbcda69f0f8b711a1~mv2.jpg/v1/fill/w_439,h_439,q_90/03a5b8_5d7459b5673445fbbcda69f0f8b711a1~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_f4fcd59894b3459ea89327a418a68649~mv2.jpg/v1/fill/w_327,h_327,q_90/03a5b8_f4fcd59894b3459ea89327a418a68649~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_b7d293663e834740ab353b8d9b7c06f6~mv2.jpg/v1/fill/w_327,h_327,q_90/03a5b8_b7d293663e834740ab353b8d9b7c06f6~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_fed193c915f642879f2a12817540cbaf~mv2.jpg/v1/fill/w_664,h_664,q_90/03a5b8_fed193c915f642879f2a12817540cbaf~mv2.jpg)
CAT5e Keystone Jack & Coupler
CAT5e SLIM KEYSTONE JACK (TOOL-LESS)
-
Category 5E UTP RJ45 Slim Keystone 16.6 x 36.5 x 22.3 mm
-
Clear plastic termination cap for terminating Cat5e Cable
-
Snap in for use with wall plates, surface-mount boxes, or unloaded patch panels
-
90˚ wire connection
Backwards compatible with previous keystone jack standards -
Colour coded T568A and T568B wiring patterns on side of jack
-
UL approved, 3P Third Party Tested, RoHS compliant, meets C5E EIA/TIA 568A/B Standard, cETLus certified
![](https://static.wixstatic.com/media/03a5b8_08a762f5cfdd4dea9e788cb111536160~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_08a762f5cfdd4dea9e788cb111536160~mv2.jpg)
Available Colour
CAT5e SLIM KEYSTONE JACK (110 PUNCH DOWN)
-
Category 5E UTP RJ45 Slim Keystone 16.6 x 31.5 x 22.3 mm
-
Use with 110 punch-down tools for speedy termination of Cat5e bulk cable
-
Snap in for use with wall plates, surface-mount boxes, or unloaded patch panels
-
90˚ wire connection
Backwards compatible with previous keystone jack standards -
Colour coded T568A and T568B wiring patterns on side of jack
-
UL approved, 3P Third Party Tested, RoHS compliant, meets C5E EIA/TIA 568A/B Standard, cETLus certified
![](https://static.wixstatic.com/media/03a5b8_25c3644078f14a3a9b55399baf5091a2~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_25c3644078f14a3a9b55399baf5091a2~mv2.jpg)
Available Colour
CAT5e SLIM KEYSTONE JACK (TOOL-LESS)
-
Category 5E In-line RJ45 Keystone Coupler (8P8C) 16.3 x 28.0 x 23.3mm
-
Use to connect two unshielded, pre-terminated RJ45 Category 5E Ethernet cables
-
Tool-less snap in for use with standard sized wall plate or patch panel
-
Meets or exceeds Cat5E EIA/TIA 568A/B standards
-
RoHS Compliant, UL Approved, 3P Third Party Tested, cETLus Certified
![](https://static.wixstatic.com/media/03a5b8_e1a7161a423847f4ad25bcab16165ac2~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_e1a7161a423847f4ad25bcab16165ac2~mv2.jpg)
Available Colour
CAT6 Keystone Jack & Coupler
CAT6 SLIM KEYSTONE JACK (TOOL-LESS)
-
Category 6 UTP RJ45 Slim Keystone 16.6 x 36.5 x 22.3 mm
-
Clear plastic termination cap for terminating Cat6 Cable
-
Snap in for use with wall plates, surface-mount boxes, or unloaded patch panels
-
90˚ wire connection
-
Backwards compatible with previous keystone jack standards
-
Colour coded T568A and T568B wiring patterns on side of jack
-
UL approved, 3P Third Party Tested, RoHS compliant, meets C6 EIA/TIA 568B Standard, cETLus certified
![](https://static.wixstatic.com/media/03a5b8_08a762f5cfdd4dea9e788cb111536160~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_08a762f5cfdd4dea9e788cb111536160~mv2.jpg)
Available Colour
CAT6 SLIM KEYSTONE JACK (110 PUNCH DOWN)
-
Category 6 UTP RJ45 Slim Keystone 16.6 x 31.5 x 22.3 mm
-
Use with 110 punch-down tools for speedy termination of Cat6 bulk cable
-
Snap in for use with wall plates, surface-mount boxes, or unloaded patch panels
-
90˚ wire connection
-
Backwards compatible with previous keystone jack standards
-
Colour coded T568A and T568B wiring patterns on side of jack
-
UL approved, 3P Third Party Tested, RoHS compliant, meets C6 EIA/TIA 568B Standard, cETLus certified
![](https://static.wixstatic.com/media/03a5b8_0969081a1e7a467f87355460d684c4c6~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_0969081a1e7a467f87355460d684c4c6~mv2.jpg)
Available Colour
CAT6 F/F COUPLER KEYSTONE JACK
-
Category 6 In-line RJ45 Keystone Coupler (8P8C) 16.3 x 28.0 x 23.3mm
-
Use to connect two unshielded, pre-terminated RJ45 Category 6 Ethernet cables
-
Tool-less snap in for use with standard sized wall plate or patch panel
-
Meets or exceeds Cat6 EIA/TIA 568B standards
-
RoHS Compliant, UL Approved, 3P Third Party Tested, cETLus Certified
![](https://static.wixstatic.com/media/03a5b8_1c07070b61d44584b83f340b2fa34f29~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_1c07070b61d44584b83f340b2fa34f29~mv2.jpg)
Available Colour
![](https://static.wixstatic.com/media/03a5b8_22b0cd82497d42bdbdaf5c749844f3b4~mv2.jpg/v1/fill/w_212,h_212,q_90/03a5b8_22b0cd82497d42bdbdaf5c749844f3b4~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_0969081a1e7a467f87355460d684c4c6~mv2.jpg/v1/fill/w_212,h_212,q_90/03a5b8_0969081a1e7a467f87355460d684c4c6~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_078932329bf745ca9264e681631d9ddd~mv2.jpg/v1/fill/w_434,h_433,q_90/03a5b8_078932329bf745ca9264e681631d9ddd~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_a7ce8a7fb94a483fa2f310755fe70e1a~mv2.jpg/v1/fill/w_341,h_340,q_90/03a5b8_a7ce8a7fb94a483fa2f310755fe70e1a~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_220187d7a336421685c6f23bf421b6a0~mv2.jpg/v1/fill/w_341,h_305,q_90/03a5b8_220187d7a336421685c6f23bf421b6a0~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_b7d293663e834740ab353b8d9b7c06f6~mv2.jpg/v1/fill/w_655,h_655,q_90/03a5b8_b7d293663e834740ab353b8d9b7c06f6~mv2.jpg)
CAT6A Keystone Jack & Coupler
CAT6A SLIM KEYSTONE JACK (TOOL-LESS)
-
Category 6A RJ45 UTP Slim Keystone (8P8C) 16.6 x 36.5 x 22.3 mm
-
Use with 10 Gigabit network applications to terminate 22-26 AWG Cat6A stranded or solid cable
-
No tool required, can use 110 punch-down tool or plastic IDC cap for tool-less terminations
-
Snap in for use with standard sized wall plates, surface-mount boxes, or unloaded patch panels
-
90 ̊ wire connection
-
Compatible and labelled with both 568A and 568B wiring color codes
-
PCB technology provides maximum performance and superior signal quality
-
Fireproof ABS UL-94V0 body
-
3P Third Party Tested, meets or exceeds C6A EIA/TIA 568C standards, ETL Intertek listed
-
Backward compatible with previous ethernet categories
![](https://static.wixstatic.com/media/03a5b8_bddd83cd602245eca71b4f93666f940f~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_bddd83cd602245eca71b4f93666f940f~mv2.jpg)
Available Colour
CAT6A SLIM KEYSTONE JACK (110 PUNCH DOWN)
-
Category 6A RJ45 UTP Slim Keystone (8P8C) 16.6 x 31.5 x 22.3 mm
-
Use with 10 Gigabit network applications to terminate 22-26 AWG Cat6A stranded or solid cable
-
Requires 110 punch-down tool to termination wire
-
Snap in for use with standard sized wall plates, surface-mount boxes, or unloaded patch panels
-
90 ̊ wire connection
-
Compatible and labelled with both 568A and 568B wiring color codes
-
50 micro-inch gold plated contacts for superior transmission, high reliability and durability
-
PCB technology provides maximum performance and superior signal quality
-
Fireproof ABS UL-94V0 body
-
3P Third Party Tested, meets or exceeds C6A EIA/TIA 568C standards, ETL Intertek listed
-
Backward compatible with Cat5, Cat5E, and Cat6 cabling
![](https://static.wixstatic.com/media/03a5b8_e91c78fa6fd5498eba9898577d140d05~mv2.jpeg/v1/fill/w_980,h_735,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/C6A-71BK.jpeg)
Available Colour
CAT6A F/F COUPLER SHIELDED KEYSTONE JACK
-
Shielded Category 6A In-line RJ45 Passthrough Coupler Keystone Jack (8P8C) 17.1 x 35.2 x 21.2 mm
-
Use to connect two pre-terminated RJ45 FTP Cat6A ethernet cables
-
Capable of transferring LAN speeds of up to 10 GB
-
Tool-less snap in for use with standard sized keystone insert, surface mount box or unloaded patch panel
-
Bronze shielding on RJ45 jack provides protection from Electromagnetic Interference and Radio Frequency Interference (EMI/RFI)
-
Faceplate size (w x h): 14.5 mm 16.1 mm height
-
50 micro-inch gold plated contacts for superior transmission, high reliability and durability
-
Compatible with T56A and T568B wiring
-
PCB technology provides maximum performance and superior signal quality
-
Meets or exceeds Cat6A ANSI/TIA/EIA 568C.2 10G and ISO/IEC 11801 standards
-
Backward compatible with Cat5, Cat5e and Cat6 Ethernet cables
-
RoHS compliant
![](https://static.wixstatic.com/media/03a5b8_b5dce4d89af942fb9b0f628db2a8e7eb~mv2.jpg/v1/fill/w_980,h_980,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/03a5b8_b5dce4d89af942fb9b0f628db2a8e7eb~mv2.jpg)
Available Colour
![](https://static.wixstatic.com/media/03a5b8_398daec88bc348dd9a8d4369ec7a1448~mv2.jpg/v1/fill/w_214,h_215,q_90/03a5b8_398daec88bc348dd9a8d4369ec7a1448~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_bddd83cd602245eca71b4f93666f940f~mv2.jpg/v1/fill/w_215,h_215,q_90/03a5b8_bddd83cd602245eca71b4f93666f940f~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_9c7e2ca1c1bb4df9aab30d1fcbaef50a~mv2.jpg/v1/fill/w_439,h_439,q_90/03a5b8_9c7e2ca1c1bb4df9aab30d1fcbaef50a~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_4cf6d091867c4514994e9104de7d6231~mv2.jpg/v1/fill/w_327,h_327,q_90/03a5b8_4cf6d091867c4514994e9104de7d6231~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_b5dce4d89af942fb9b0f628db2a8e7eb~mv2.jpg/v1/fill/w_327,h_327,q_90/03a5b8_b5dce4d89af942fb9b0f628db2a8e7eb~mv2.jpg)
![](https://static.wixstatic.com/media/03a5b8_3ef0783e21a0420a9eaa6ea9fc3e77d7~mv2.jpg/v1/fill/w_664,h_664,q_90/03a5b8_3ef0783e21a0420a9eaa6ea9fc3e77d7~mv2.jpg)
